Cylindrical winding packing machine carries on the axial packing to the cylindrical object, realizes the integral wrapping of the object. It is beneficial to the storage, transportation and turnover of goods, and has the function of dustproof, moisture-proof and cleaning.
Its packing cost is low, the efficiency is high, exaltation packing class. At the same time, according to the actual needs of packaging, can choose cylinder - tray dual type, automatic ejecting type, automatic on-line equipment.
Scope of application and advantages:
· Suitable for the packaging of web, non-woven fabrics and other products
· Achieve a full range of coating of goods
High quality products · Start with details
Product technical parameters:
model
LP3-P
Wrapped around the specifications
The diameter
Ф（500-1500）
width
500-1600
Overall dimensions
L×W×H
3200×2000×2200mm
Turntable diameter
φ2000 mm
Turntable bearing
2000kg
Support drive mode
Nylon roller + chain
Turntable height
460/530mm
power
1.5kw；0.4kw；0.37kw；0.35；380VAC/50HZ/20A
The weight
1080kg
The packing efficiency
20-40 pieces/hour
Rotary speed
0-12 RPM variable frequency adjustable
The membrane system
Pre-stretching film frame, pre-stretching up to 250%, automatic film feeding, film feeding speed can be adjusted
Control system
PLC control, the number and number of winding layers can be adjusted
Special specifications can be customized, please contact the company's technical engineers;
The values in the table are for reference only, and are subject to change without prior notice. Please contact our technical engineer for detailed information.
